Part number:
214-BR424-1751
Rear 17" x 2.15" Dirt Bike Rim Wheel
Version 1751
Chinese rear rim wheel for 110cc and 125cc dirt bikes. This size is used on several makes and models including Tao Tao dirt bikes. Please use detailed measurements and pictures to help you get the correct rim for your machine.
Wheel details:
- Rear
- Black with silver spokes
- Silver hub
- 17" x 2.15"
- 36 spokes
- Center hole diameter: 15mm [.59"]
- Overall width of rim: 77.7mm [3.05"]
- Overall rim diameter: approx 45.7cm [18"]
- Bolt hole spacing: 64mm [2.5"] center to center on sprocket side
- Bolt hole spacing diagonally: 90mm [3.55"] on sprocket side
- Bolt hole spacing: 57mm [2.24"] center to center on brake rotor side
- Bolt hole spacing diagonally: 80mm [3.15"] on brake rotor side
- 8mm*1.25 threaded bolt holes on brake rotor side
- Used with 110/90-17 tire
- 607289
The last number on your TIRE will let you know if you are needing a 17" rim. This is a 17" rim.
